The surface magnetic lock uses an electrical current to produce a magnetic force against the door frame and the leaf, securing it in place. What’s different about these products to other mechanical lo
The surface magnetic lock uses an electrical current to produce a magnetic force against the door frame and the leaf, securing it in place. What’s different about these products to other mechanical locks is that you won’t require a key; all you simply have to do is rely on your access control systems to allow you to gain access through the door. The Deedlock 600kg Surface Magnet Lock Superior Duty 12/24v DC is perfect if your door has a holding force of 600kg. You can even have a dual action of 12 or 24V DC on your surface magnetic lock, which is an uncommon feature for other magnetic locks.
- CE marked • Low maintenance with no moving parts
- Safety bolts prevent the magnet from detaching from the bracket itself
- Dual voltage 12 / 24V DC (Selectable on site)
- Suitable for single or double doors, Inward or outward opening
- Satin anodised aluminium finish
- For medium to high usage traffic applications
- Minimum holding force: Grade 4 – 5000N (1124 lbs/f)
- Tested Holding Force: 5900N (1326 lbs/f) (600 kg/f)
Additional information
| Dimensions | 288 × 73 mm |
|---|---|
| Finish | Satin Anodised Aluminium |
| Condition | new |
| Warranty | 1 Year |
| Fixings Included | Yes |
| Depth | 40 |
| Width | 288 |
| Height | 73 |
| Product Type | Surface Magnet |
| Can Be Fitted | Surface |
| Input Voltage | 12/24v dc |
| Holding Force | 600kg |
| Monitored | No, Yes |
| Internal | Yes |
| Delivery Type | Standard |
