12v 1 amp DC Switch Mode Power Supply Small Case ADP121A
12v 1 amp DC Switch Mode Power Supply Small Case ADP121A
The 12v DC Switch Mode Power Supply Small Case ADP121A is a high efficiency, cost effective switch mode power supply to be used with Access Control, CCTV and general purpose applications. Modular cons
The 12v DC Switch Mode Power Supply Small Case ADP121A is a high efficiency, cost effective switch mode power supply to be used with Access Control, CCTV and general purpose applications. Modular construction allows for simple maintenance and upgrade capability.
Featuring a regulated highly stable output supplying a full rated current to load and a universal mains voltage input (90 to 264 Volts a.c.)
12v DC Switch Mode Power Supply Small Case ADP121A- Efficient Switch Mode Operation
- Closely Regulated 13.8Vdc Output
- 1, 2 & 3 amp options available
- Full Rated Current to Load + 0.5A battery charging
- Universal Mains Voltage Input 90V – 264V ac
- Electronic Overload Protection
- Mains Transient Protection
- Front Tamper Protection
- Mains Status LED Indication
- Hinge lid
You’ll need a 12V power supply for a consistent running of your security systems or other purposes you may use it for. But with 12v DC Switch Mode Power Supply Small Case ADP121A it features just one amp making it suitable for use on small systems that requires only one power source.
Additional information
| Dimensions | 200 × 240 mm |
|---|---|
| Finish | White |
| Condition | new |
| Warranty | 1 Year |
| Material | Metal |
| Fixings Included | Yes |
| Depth | 75, 85, 90 |
| Width | 200, 330, 360, 375 |
| Height | 240, 330, 335, 360 |
| Product Type | 12v Power Supply, 24v Power Supply |
| Number of Fused Outputs | 1 |
| Input Voltage | 90-264v ac @50-60Hz |
| Output Voltage | 13.8v dc, 27.6v dc |
| Output Amps | 1 Amp, 2 Amps, 3 Amps, 5 Amps |
| Battery Charging | Yes |
| Internal | Yes |
| Delivery Type | Standard |
